Zotac N340N3 ideal for Analytics or vibrant UltraHD Digital Signage

ZOTAC Jetson N340N3 Fanless Industrial mini-pc

Uniqueness and next level performance define the Zotac N340N3, our latest ARM based platform featuring NVIDIA® Jetson™ TX2, the latest and most advanced Supercomputer-on-Module. The Zotac N340N3 unleashes the incredible power of a 64-bit quad-core ARM® Cortex® – A57 CPU combined with NVIDIA Pascal GPU with 256 NVIDIA CUDA® Cores in your most demanding applications. Its improved power-efficiency, unparalleled 4K capabilities with H.265 and VP9 native support and unprecedented GP-Computing potential make the N340N3 the most powerful and versatile ARM platform we’ve created … so far.

A fanless design and total lack of moving parts enables this unit to be reliably installed even at the most sound-sensitive and adverse location (Rated to 60 deg C).

A pre-loaded Linux OS provides the gateway to countless industrial applications available on the market today. Whether your needs are for an analytics or for a vibrant UltraHD Digital Signage showcase, the Zotac N340N3 is engineered to exceed your expectations.


Computing System Module NVIDIA® Jetson™ TX2

Processor                                           HMP Dual Denver 2/2 MB L2 + Quad ARM® A57/2 MB L2

System Memory                                  Onboard 8GB LPDDR4 RAM, up to 59.7GB/s bandwidth

Graphics Engine                                 NVIDIA® Pascal GPU, 256 NVIDIA CUDA®cores OpenGL 4.5, OpenGL ES 3.1, AEP and Vulkan™ 1.0

HD Video Capability                            HDMI 2.0 4K x 2K @ 60 Hz, 1080p @ 120 Hz, H.265 VP9 4K 60 fps Video 4k H.265, 4k VP9, 4k H.264, HDCP 2.2

Storage                                               32GB eMMC flash on SoM

Card Reader                                       SD/SDHC/SDXC

Video Output                                       1x HDMI 2.0, 1x DisplayPort 1.2

USB Port                                             2 x USB 3.0 Type-A, 2 x USB 2.0 Type-A

LAN                                                     1 x Gigabit LAN

Antenna                                               2 x WiFi SMA connector

WiFi                                                     IEEE 802.11ac/a/b/g/n 2×2 MIMO

Bluetooth                                             Bluetooth 4.0

Legacy I/O                                           1 x RS232 serial port

Dimensions                                         160 x 132 x 51mm

PSU                                                     Universal AC Adapter DC 12V/60W

OS                                                       Linux for Tegra R28.1 based on Ubuntu 16.04 64-bit, Kernel 4.4
